ItalianoSeries
R2MH NC
Solenoid Valve 2 ways – Combined Acting.
Normally Closed
Description
Functioning
Solenoid Valve 2/2 ways
Combined Acting, Normally Closed
Body material
Brass CW617N
Pipe Size
G3/8” – G1/2″ – G3/4″ – G1″
nomimal diameter
From 13mm to 25mm
KV
From 2,2m3/h to 10,2 m3/h
SEAL
NBR, FKM, EPDM
MOPD Differential Pressure
From 0 bar min to 16 bar max
temperature range
From -10°C to +160°C
Options
Electroless nickel plating
Degreased for Oxygen use
Others on request
Applications
Water supply
Automation and industrial controls
Industrial and Noble gases Control
Tank Discharge
Air and Regriferation Compressors
Vacuum
Industrial Oxygen
Steam generators
Ammonia
Fuel management
